Heathkit GR-78 General Coverage Radio Receiver Shortwave Assembly Operation Manual

This is a difficult to find Assembly and Operation Manual for the Heathkit GR-78 General Coverage Receiver. This well written and illustrated manual is absolutely required to repair or recondition these fine solid state radio receivers. This booklet helps to understand how an double conversion superheterodyne receiver works and it includes the instrument's design description, construction help, circuit diagrams and operating instructions.
Heathkit GR-78 General Coverage Radio Receiver Shortwave Assembly Operation Manual [6 KB]
SPECIAL - HARD TO FIND ITEM

Features:

Manual for Heathkit GR-78 General Coverage Receiver
Assembly notes with schematic diagrams
Design information - Calibration - Operation
Circuit description - Parts Lists
Alignment with instruments - Specification
124 Pages, many foldouts - 1970
Size: 8.5 W x 11 H x 0.25 D [in]

Notes:

Price: E-Mail for price and availability
