Heathkit HD-1250 Solid-State Dip Meter Assembly Operation Manual Transistor GDO

This is a difficult to find Assembly and Operation Manual for the Heathkit HD-1250 Solid-State Dip Meter, a transistorized version of the classic GDO (Grid Dip Oscillator). This well written and illustrated manual is absolutely required to repair or recondition these fine solid state instruments. This booklet helps to understand how a dip oscillator meter works and it includes the instrument's design description, construction help, circuit diagrams and operating instructions.
Heathkit HD-1250 Solid-State Dip Meter Assembly Operation Manual Transistor GDO [6 KB]
SPECIAL - HARD TO FIND ITEM

Features:

Heathkit HD-1250 Solid-State Dip Meter Manual
Assembly notes with schematic diagrams
Design information - Calibration - Operation
Circuit description - Parts Lists
Alignment with instruments - Specification
70 Pages, many foldouts - 1975
Size: 8.5 W x 5.5 H x 0.2 D [in]
