Heathkit IB-101 Frequency Counter Assembly Operation Manual Digital Precision

This is a difficult to find Assembly and Operation Manual for the Heathkit IB-101 Frequency Counter with a digital, crystal controlled time base and a five digit display. This manual is absolutely required to repair or recondition these great instruments. This manual help to understand how frequency counters work and it includes the instrument's design description, construction help, circuit diagrams and operating instructions.
Heathkit IB-101 Frequency Counter Assembly Operation Manual Digital Precision [6 KB]
SPECIAL - HARD TO FIND ITEM

Features:

Heathkit Model IB-101 Frequency Counter
Assembly notes with schematic diagrams
Design information - Calibration - Operation
Circuit description - Parts Lists
58 Pages, many foldouts - 1970
Size: 8.5 W x 11 H x 0.125 D [in]

Notes:

Original manual - Price: $20 - One available
S/H included within continental US
