5R4GYA Full-Wave Vacuum Medium-Voltage Rectifier Sylvania Vacuum Tube Reference

This is a genuine, vintage, Sylvania 5R4GYA electronic tube. Used for medium-voltage low-current full-wave rectifier applications, in radio receivers or RF equipments. At one time these tubes were used in many special circuits, receivers, transmitters and transcievers. This medium HV (High Voltage) Full-Wave vacuum rectifier tube is excellent for antique radio and television TV restoration projects or to set up a private vacuum tube museum. This tube is no longer Available.
5R4GYA Full-Wave Vacuum Medium-Voltage Rectifier Sylvania Electronic Vacuum Tube [11 KB]
REFERENCE PAGE - INFORMATION ONLY

Features:

5R4GYA Full-Wave Vacuum Rectifier
Medium-High Voltage [HV] dual diode
MFG: Sylvania
Filament: 5 V, 1.2 A
Plate: 1,250 Vmax, 375 mAmax - Per plate
Base: 8-pin octal
Quality Made in USA

Notes:

No longer Available
Data For Reference Only
5R4GYA Octal 8-Pin Electronic Vacuum Tube Electrode Connections
PIN # 1 2 3 4 5 6 7 8
Electrode - Heater - Anode 1 - Anode 2 - Heater
