Heathkit IO-105 Dual-Trace Oscilloscope Assembly Operation Manual Circuit Parts List

This difficult to find Assembly and Operation Manual for the Heathkit IO-105 Dual-Trace Oscilloscope. This manual is absolutely required to repair, recondition or build one of this excellent device. This booklet helps to understand how a solid state oscillosope works and it includes the circuit's design description, construction help, circuit diagrams, parts list and operating instructions.
Heathkit IO-105 Dual-Trace Oscilloscope Assembly Operation Manual [8 KB]
SPECIAL - HARD TO FIND ITEM

Features:

Heathkit IO-105 Dual-Trace Oscilloscope Manual
Assembly notes with schematic diagrams
Design information - Calibration - Operation
Circuit description - Parts List
190 Pages, many foldouts - 1971
Size: 8.5 W x 11 H x 3/8 D [in]

Notes:

Price: E-Mail for price and availability
