3BZ6 Semiremote Cutoff Pentode RF Amplifier Miniature RCA Vacuum Tube 2

This is an original RCA 3BZ6 Semiremote Cutoff Pentode electronic vacuum tube. It is a collector's special rare but fully functional antique device. This seven pin, all glass, miniature type used as RF or IF amplifier, usually in class-A configuration in many instruments, radio and television (TV) receivers. Excellent part for antique radio or television restoration. It is a NOS tube [New Old Stock], unused, boxed, excellent condition. One available.
3BZ6 Semiremote Cutoff Pentode RF Amplifier Miniature RCA Vacuum Tube 2 [18 KB]
HARD TO FIND ORIGINAL HISTORICAL TUBE

Features:

3BZ6 Semiremote Cutoff Pentode
MFG: RCA Quality Made in USA
RF Amplifier, Oscillator
Heater: 3.15 V, 0.6 A
Plate: 330 Vmax 2.3 Wmax
Base: 7-pin miniature, all glass Collectible

Notes:

NOS - [New Old Stock] tube Standard box
Unused Price: $15 One available
S/H included within continental US
3BZ6 Miniature 7-Pin All Glass Electronic Vacuum Tube Electrode Connections
PIN # 1 2 3 4 5 6 7
Electrode Grid 1 Cathode Heater Heater Anode Grid 2 Grid 3 IS
IS=Internal Shield
